WM-605 Urine Test Strip Automatic Roll Cutting Machine
wm 605 urine test strip automatic roll cutting machine
WM-605 Urine Test Strip Automatic Roll Cutting Machine
wm 605 urine test strip automatic roll cutting machine

WM-605 Urine Test Strip Automatic Roll Cutting Machine

Scope of Application:

Single-strip cutting production for urine test strips.


Optimize Your Production Precision

WM-605 Urine Test Strip Automatic Roll Cutting Machine Specifications

ModelWM-605
Rolling Cutting PrecisionError ±0.05mm (There may be slight fluctuations depending on the material)
Silo Capacity300 sheets
Cutting ThicknessFlat surface within 0.15mm
Suitable Size60-130mm
Suitable Bottle Size38-50mm
Edge Material HandlingAutomatic removal of edge material
NoiseLower than 70 decibels
Static Electricity Removal and Dust Suction FunctionCan be added (optional)
Cutting Efficiency16-18 bottles per minute (100 pieces including desiccant)
Gas Source0.6Mpa (Clean gas source)
Machine Size960mm*600mm*1200mm,Equipment dimensions may vary depending on the work surface configuration.
Electric Power ConsumeAbout 3.4KW
Electric PowerAC220V/50,60HZ
Machine WeightAbout 880KG


WM-605 Urine Test Strip Automatic Roll Cutting Machine Workflow

Automatic feeding
Automatic feeding
Alignment
Alignment
Roll cutting
Roll cutting
Automatic bottling
Automatic bottling
WM-605 Urine Test Strip Automatic Roll Cutting Machine Advantages

WM-605 Urine Test Strip Automatic Roll Cutting Machine Advantages

• The entire system is enclosed with an external protective cover and equipped with a dust extraction system for effective dust control. The equipment performs automatic material pickup, edge alignment, automatic collection, desiccant dispensing, and the production process is monitored in real time by a CCD vision system. It features high speed, high efficiency, and stable quality—an ideal production device for manufacturers.

• The bottle loading system adopts a platform-style feeding design, capable of holding 500–600 bottles at a time.
