This equipment is a one-piece die-cutting machine developed for manufacturers requiring standard-shaped test strip substrates with positioning hole functionality.
The device can be optionally equipped with automatic detection of specific markings and automatic correction capabilities, offering fast speed, high efficiency, and stable quality, making it an ideal production auxiliary equipment for manufacturing enterprises.
Molds can be customized to meet various requirements, enabling simultaneous formation of both the substrate positioning hole and the final shape.
The mold is manufactured from imported SKD-61 alloy material from Japan and undergoes vacuum heat treatment, ensuring excellent wear resistance. It can also be customized with surface titanium treatment.
Scope of Application:
Processing of drilling and die-cutting of base materials for diagnostic items such as blood glucose and blood lipids.
| Model | WM-201 |
| Worktable Route | 100mm-650mm (According to the sheet's real size to confirm) |
| Cutting Precision | Within ±0.03mm |
| Suitable Thickness | Within 1mm |
| Cutting Way | Die cutting and shaping |
| Maximum Size | 100mm×450mm |
| Maximum Punching Pressure | Gas-liquid supercharging way, 3T-10T (Configuration can be selected) |
| Machine Size | 760mm×600mm×1500mm (The size and shape will be different according to customized requirements) |
| Gas Source | 0.6-0.8Mpa (Clean gas source) |
| Machine Weight | About 90-760KG |
| Electric Power Consume | About 1.3KW |
| Electric Power | AC220V/50, 60HZ |
• Optional automatic mark sensing and correction function for precise positioning. The system operates with high speed, efficiency, and stability, making it an ideal auxiliary production device.
• Custom molds can be manufactured to form positioning holes and external contours in a single process, based on production requirements.
